Shaft diameter 12.7/14mm
Motor length 139mm
Motor Weight 3.98 Kg
Current / Phase 6A
| Model | Step angle | Current (A) | Resistance (Ω±10%) | Inductance (mH±20%) |
Holding torque (N.m) | Motor length (mm) | Encoder Resolution (PPR) |
Weight (kg) |
| 86HSE4N-BC38 | 1.8° | 6.0 | 0.45 | 3.7 | 4.5 | 82 | 1000 | 2.65 |
| 86HSE8N-BC38 | 1.8° | 6.0 | 0.44 | 3.7 | 8.0 | 118 | 1000 | 4.0 |
| 86HSE12N-BC38 | 1.8° | 6.0 | 0.45 | 5.2 | 12.0 | 156 | 1000 | 5.65 |
