$75.00 - $89.00
This 62mm Brushless DC Planetary Geared Motor provides high torque and low vibration performance, making it an ideal choice for industrial machinery. Its high-efficiency design ensures a long-lasting motor with a high power density
Motor Type Brushless Planetary Gear Motor
Output Power (W) 60/90
Voltage (V) 24
Rated Speed (r/min) 3000
| Ratio | 3.65 | 5.36 | 6.55 | 8.63 | 14 | 19 | 25 | 28 |
| Out-put Speed(rpm) | 822 | 560 | 458 | 348 | 222 | 159 | 122 | 107 |
| Allowable Torque(N.m) | 0.63 | 0.92 | 1.13 | 1.48 | 2.17 | 2.94 | 3.87 | 4.33 |
| Reduction Stage | 1 | 1 | 1 | 1 | 2 | 2 | 2 | 2 |
| Ratio | 34 | 45 | 58 | 67 | 81 | 91 | 103 | 119 |
| Out-put Speed(rpm) | 89 | 67 | 52 | 45 | 37 | 33 | 29 | 25 |
| Allowable Torque(N.m) | 5.26 | 6.96 | 8.97 | 9.34 | 11.3 | 12.69 | 14.36 | 16.6 |
| Reduction Stage | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 |
| Ratio | 128 | 146 | 165 | 192 | 232 | 302 | 393 | - |
| Out-put Speed(rpm) | 24 | 21 | 18 | 16 | 13 | 9.9 | 7.6 | - |
| Allowable Torque(N.m) | 17.85 | 20.36 | 23.01 | 26.77 | 32.35 | 42 | 45 | - |
| Reduction Stage | 3 | 3 | 3 | 3 | 3 | 3 | 3 | - |
